Hybrid Anaerobic Digester Systems

The FARM range of digesters are larger systems; enabling a variety of solid wastes such as manures, silage, crops and vegetation to be digested. An enhanced model conforming to ABPR Cat 3 enables the digestion of large volumes of food and animal by-product wastes.

FARM250 – Mixed Waste Digester, such as FYM and vegetation with daily inputs of 4 to 5 tonnes.
FOOD250 – Large Scale ABPR Cat 3 Digester for food and animal by-product wastes with daily inputs of 4 to 10 tonnes (depending upon DM rate)
FARM500 – Larger version of the FARM250 with daily inputs of 8 to 10 tonnes of mixed waste.

	Feedstock (example)	Capacity Tonnes per day	Estimated BioGas Yield m³/hr	Potential Electricity kW	Potential Heat kW
FARM250	Farm yard manures Slurry	4 - 5 manure 15 - 20 slurry	12 – 15	20 – 30*	35 - 60
FOOD250	Organic, Food, Animal by-product wastes	4 – 10	10 – 20	15 – 40*	25 - 100+
FARM500	Farm yard manures Slurry	8 - 10 manure 30 - 40 slurry	25 - 30	45 - 60*	75 - 120

*The above calculations are for illustration only. Biogas yield and therefore electricity output is variable due to factors such as % dry matter, volatile solids, age of feedstock, inhibitors and % methane in the biogas.

Discover our FARM series in more detail

Take a closer look at the FARM250 and learn how each step of the anaerobic digestion process takes place.

Is this system right for me?

Our team can guide you through a completely FREE, no obligation process to evaluate your establishment and available feedstock. Once we are confident that the required outputs can be achieved our team will begin the next step of the evaluation process, which includes sample collection and detailed feedstock analysis.
